L・eye Photovoltaic Package High voltage

High voltage 3 Power receiving and transforming
500kW or more, less than 1MWINV+SRTS+RTE *For Type C, only inverter

Back to Package Overview

Package contents and installation conditions

Storage board

Storage board
Storage board(type) Type C
Size W700×H600×D300mm
Weight Approx. 45kg(Including UPS)
Power supply 100V
Contents Measuring instrument Solar Link ZERO, AC adapter, FLIPLINK, Breaker, Terminal block, UPS, OA tap, RS-485 SPD (LAN SPD), Power SPD
material properties Iron
IP standard IP54(Storage board only)
Storage board
Storage board(type) Type D
Size W700×H800×D300mm
Weight Approx. 55kg(Including UPS)
Power supply 100V
Contents Measuring instrument Solar Link ZERO, AC adapter, FLIPLINK, Breaker, Terminal block, UPS, OA tap, RS-485 SPD (LAN SPD), Power SPD
Material properties Iron
IP standard IP54(Storage board only)

Measuring Instruments

Solar Link ZERO
Solar Link ZERO Case image Click here for product details
FLIPLINK
FLIPINK Case image Click here for product details

Specification

・Common specifications

  • ・Communication line between on-site and remote monitoring servers※1
  • ・Remote monitoring and display system ASP service※2
  • ・Measuring equipment

※1 Please check the coverage area in advance.
※2 Please pay the ASP service fee and communication line fee in one lump sum.

・Installation conditions

  • ・There are restrictions on the type and number of inverters that can be connected.

・Equipment warranty

  • The measurement terminal will be guaranteed for the number of years of the contract, and other equipment will be guaranteed for one year.
    In addition, the equipment warranty for the measurement terminal will continue even if the contract is extended.
  • When adding the camera image option
  • The measurement terminal and camera peripherals will be guaranteed for the number of years of the contract, and the web camera body and other equipment will be guaranteed for one year.
    In addition, the equipment warranty for the measurement terminal and camera peripherals will continue even if the contract is extended.

・Alternative line warranty

  • If the communication line service at the time of the contract ends in the future, we will provide you with a separate alternative line.
